Washing system for industrial vehicles

MOD. TITAN
THE GIANT IN THE WASHING OF COMMERCIAL, INDUSTRIAL VEHICLES AND PUBLIC OR PRIVATE MEANS OF TRANSPORT
Main Features:
Hot dip galvanized structure with fixing screws in stainless steel. The electrical board is assembled in a water proof cabinet and located inside the left side column. While all lifting chains, stainless steel guides for the trolley sliding and compartment for chemical products are placed in the right vertical column
Brushes in PE with specific program to avoid vehicles' mirrors and electronic system to control the pressure on the vehicle
Arches with nozzles for the uniform distribution of the chemical products on the whole vehicles surface
Adjustable electronic dosing pump to optimize the consumption of chemical products
Anti-tipping rails in hot dip galvanized steel
Hot dip galvanized poles to support electrical cables and hydraulic pipes that feed the rollover
Trafic light at the lift side
Electrical board assembled in a sturdy water proof cabinet that is placed in the side column with PLC to control all functions and washing cycles
Available optionals:
PASSING-THROUGH UNDERCHASIS 50 BAR 100 Lt\Min 9,2 Kw
SIDE HIGH PRESSURE 50 BAR 100 Lt\Min 9,2 Kw
CIRCUIT FOR FEEDING WITH RECYCLED WATE
PRE-WASH ARCH
SIDE SPRAYGUARDS
AUTOMATIC SYSTEM FOR ANTI-ICING EMPTYING FOR ALL CIRCUITS
CUSTOMIZED WASHING PROGRAMS
